How We Install the Jandy TruClear XL Salt Chlorinator
How We Install the Jandy TruClear XL Salt Chlorinator
Looking to enjoy crystal-clear pool water without the hassle of traditional chlorine? At Oasis Lighting Design, we recently installed a Jandy TruClear XL Salt Chlorinator for a residential client—and here’s a quick breakdown of how it works and how we install it professionally.
What Is a Salt Chlorinator?
The Jandy TruClear XL is a powerful salt chlorinator that turns ordinary salt into pure chlorine, keeping your pool water clean and safe—without the harsh chemical feel. It’s ideal for pools up to 45,000 gallons and automatically produces chlorine as your system runs.
What You’ll Need
Before we begin installation, we always ensure the following:
- Proper salt level: 3000 ppm minimum
- Clean, balanced pool water (tested for pH, calcium, stabilizer, etc.)
- A horizontal 2” or 2.5” return line section, at least 16" long
Installation Steps
1. Water Chemistry First
We test and balance the water—checking calcium hardness, pH, stabilizer (CYA), and salt levels. Poor water chemistry can ruin the system and void your warranty.
2. Pipe Prep
We select a straight, horizontal pipe section after all pool equipment (filter, heater, etc.), then cut a 14.5” gap for the chlorinator cell.
3. Install the Cell
The cell is cemented in place with union fittings and aligned with the correct flow direction. We ensure no leaks and let the cement dry completely.
4. Electrical Setup
Our licensed team wires the TruClear XL to a GFCI-protected breaker and bonds it to your existing pool equipment ground. It’s always interlocked with the pool pump—so it only runs when water is flowing.
5. Salt Addition
If needed, we add high-purity, non-iodized salt (≥99.8% NaCl) directly into the pool—not through the skimmer—and circulate the system for even mixing.
6. Startup & Configuration
Once salinity is confirmed, we power on the chlorinator, set the chlorine output (typically 40–60%), and educate you on how to monitor and maintain it weekly.
Resources
Need your salt system installed right the first time? Contact Oasis Lighting Design — we’ll ensure it’s done safely and efficiently.
Gallery
Jandy TruClear XL cell installed on return plumbing
Jandy TruClear XL cell Motherboard
Jandy TruClear XL cell Final Result
Final Result
